We offer a complete solution for launching our own production in Europe and all over the world:
Technology and power
Produce up to 5,000 tons of charcoal briquettes, up to 15,000 tons of wood or torrefied briquettes, and 30,000 tons of pellets per year. For example, 20-25 m3 of bulk sawdust is needed to produce 1 ton of charcoal briquettes.
Equipment
Use iNOS GLOBAL's own European equipment to build and launch a production line.
All components have been tested for many years and are optimized for quick start-up and long-term operation. The quality is confirmed by certificates
Service
Cooperate with the INOS GLOBAL team at all stages of the plant start-up: we will advise on the production schedules of the start-up, ensure the supply of equipment, conduct installation supervision and commissioning, and assume warranty obligations
F|
Produce competitive products with high consumer demand:
Сharcoal briquette
Your factory's charcoal is both an energy-efficient solution and a more eco-friendly product than its counterparts
Wood briquette
Produce high-calorie briquettes using unique technologies
Torrefied briquette
Due to the torrefaction process, it is more calorific than wood briquettes: moisture evaporates, carbon, hydrogen and oxygen are released
Pellets
Fuel pellets are biofuels obtained from wood waste. It is in high demand in many production areas
F|
Produce competitive products with high consumer demand:
С|
Your plant's coal briquette is both an energy-efficient solution and a more environmentally friendly product than its counterparts
W|
Produce high-calorie briquettes using unique technologies
Т|
Due to the torrefaction process, it is more calorific than wood briquettes: moisture evaporates, carbon, hydrogen and oxygen are released
P|
Fuel pellets are biofuels obtained from wood waste. It is in high demand in many production areas
Overview |
Get a visual view of your factory in 1 minute 10 seconds
Get answers to your questions from a representative in Irkutsk. Send a request and we will call you back today:
Overview |
Get a visual view of your factory in 1 minute 10 seconds
Get answers to your questions from a representative in Irkutsk. Send your request and we will contact you today
P|
The equipment is manufactured in Latvia, delivered on EXW Salaspils terms, and has a CE certificate
For charcoal briquettes
For wood briquettes
For torrefied briquettes
For pellets
P|
Sieve; Sieve; 2; Separation of large fractions of sawdust before drying (Hydrotreating)
;Screw conveyor for feeding sawdust; 2
;Dosage Valve; 2
;Conveyor for removing large fractions into the container; 2
Drying;Steel pipe 1 m in diameter, including calipers; 1; Drying of sawdust by means of temperature and steam
;Circulation Fan; 1
;Transport Fan with drying; 1
;Valve; 1
Firebox; Movable grates, moving floor, hydroelectric station; 1; Air Heating
;firebox Pusher; 1
;3 MGW Firebox; 1
;Ash Pusher; 1
;MIH chamber (concrete and brick); 1
;Set of chimneys; 1
P|
; Pellet press; 1; Pellet Press
P|
P|
;Cyclone; 1; Pressing sawdust into briquettes and sawing to size
;Mixer with screws; 1
;Briquette press; 2
;Cooling Line with tires; 2
;Gas exhaust Collector, fan and cyclone; 2
;Cutting moving saw with aspiration system and filter; 2
;Carriage for briquettes with tires; 10
P|
;Pyrolysis chamber with a heating chamber (battery); 2; Obtaining charcoal briquettes by pyrolysis
;Loading/unloading Station with a pusher and a screw; 2
;MIH Chamber with a "bridge" valve; 1
;Chimney with an arson function;2
P|
;Stabilization chamber with additional heating chamber; 1; Stabilization of charcoal briquettes
;loading/unloading Station with pusher and screw; 1
;Control System with valves and hatches; 1
C|
;General control system from the process control center (one PC and 2 screens); 1; Control system for drying, pressing, pyrolysis and stabilization and process control
;Control Panel with emergency button; 1
;Main power cabinets; 1
;Container for power cabinets; 1
T|
;Trolley for briquettes in the disassembled state (in the form of modules); 100; Moving briquettes from briquetting to pyrolysis and stabilization
;Caps for briquettes in the disassembled state (in the form of modules); 20
;Trolley for briquettes in the disassembled state (in the form of modules); 100; Moving briquettes from briquetting
W|
in 2021, INOS GLOBAL provides deliveries and related services for the launch of the plant in any region
